Logic Controls MR3000-BK Credit Card Reader

Logic Controls MR3000 - Tracks 1 and 2, Fully programmable, steel case, PS/2 interface, Color: Black

The MR3000 Magnetic Stripe Reader (MSR) family features a built-in decoder to read tracks 1 and/or 2. The housing is made of a specially designed, heavy die cast steel for unsurpassed stability. Stainless steel card guides give cards an extra smooth ride. The bi-directional reading head uses a highly durable material not found in most units today. A two color LED indicates a Good/Bad reading. This unit can operate with or without the conventional 101 keyboard being attached. Wedge and RS-232 interfaces available.

General Information

• Product Type: Magnetic Stripe Reader

• Brand Name: Logic Controls

• Manufacturer: Bematech

• Product Model: MR3000-BK

• Product Name: MR3000-BK Magnetic Stripe Reader

Technical Information

• Magnetic Stripe Track Configuration: Dual Track

• Magnetic Stripe Track Number:Magnetic Head Life: 1000 Swipe

  • Track 1

  • Track 2

Physical Characteristics

• Height: 1.3"

• Width: 5.7"

• Depth: 1.8"

• Color: Black

• Weight (Approximate): 1.20 lb

Interfaces/Ports

• Interfaces/Ports: PS/2 Keyboard Wedge

Warranty

• Limited Warranty: 1 Year

Power Description

• Input Voltage: 5 V DC
